Technical Parameters | |
Operating temperature | -40℃~+105℃ |
Relative humidity | 90%～95%(40%P2℃) |
Working air pressure | 4.39KPa~101.33KPa |
Vibration | 10～2000Hz,196m/s2^,momentary interruption≤1μs |
Shock | 980m/s2^, instantaneous interruption ≤1μs |
Operating voltage | 600V |
Withstand voltage | 2500V |
Working current | 7.5A |
Contact resistance | ≤5mΩ |
Insulation resistance | ≥5000MΩ |
Mechanical life | 500 times |
Waterproof grade | IP67 |
Salt spray resistant | 48 hours |
