Technical Parameters | |
Number of contacts | 7-core |
Storage temperature | -43℃~+70℃ |
Operating temperature | -43℃~+60℃ |
Rated current | 5A. |
Pressure resistance | 1800V |
Operating voltage | 600V |
Contact resistance | Initial ≤10mΩ |
Insulation resistance | Normally ≥3000MΩ |
Salt spray test | Meets the 96H salt spray test requirements specified in GJB 150.11A-2009 |
Mechanical life | ≥300 times (connection and separation) |
Waterproof grade | IP66,IP67 |
