Technical Parameters | |
Operating temperature | -40℃~+125℃ |
Relative humidity | 90%~95%(40±2C) |
Current | 1A |
Operating voltage | 125v |
Vibration | 10-500Hz, acceleration 98m/s² |
Shock | 3ms half sine wave, peak acceleration 294m/s² |
Contact resistance | ≤0.04Ω |
Insulation resistance | Normal temperature ≥500MΩ; wet heat ≥20MΩ |
Mechanical life | 500 times |
Waterproof grade | IP67 |
Salt spray resistant | 48 hours |
