Technical Parameters | |
Operating temperature | -40 C~+105 C |
Relative humidity | 90%~95%(40±2 C) |
Working air pressure | 4.39KP~101.33KP |
Vibration | 10~2000Hz,960m/s²,momentary interruption≤1μs |
Shock | 980m/s² |
Operating voltage | 600V; Withstand voltage: 1500V |
Working current | 50A |
Contact resistance | ≤1mΩ |
Insulation resistance | ≥5000MΩ |
Mechanical life | 500 times |
Waterproof grade | IP67 |
Salt spray resistant | 48 hours |
