Technical Parameters | |
Number of contacts | 4-core |
Operating temperature | -40℃~105℃ |
Rated current | 50A |
Insulation resistance | ≥5000MΩ |
Mechanical life | ≥500 times (connection and separation) |
Contact diameter | φ3.45. |
Operating voltage | 300V/AC. |
Contact resistance | ≤1mΩ(when plugged in) |
Salt spray test | 96H |
Waterproof grade | IP67 |
Product Materials | |
Case | Stainless steel |
Cover | Insulator |
Contacts | Copper gold plated |
