Technical indicators | |
Working temperature | -40 ～ +125℃ |
Relative humidity | 90% ~95%(40±2℃) |
Working air pressure | 4.39KPa~101.33KPa |
Salt spray performance | 48-120h |
Waterproof level | IP67, up to dynamic IP68 |
Working voltage | 1000V |
Vibration | 10 ～ 2000Hz, 196m/s2, instantaneous interruption ≤ 1μs |
Shock | 980m/s2, instantaneous interruption ≤ 1μs |
Mechanical life | 500 times |
Insulation resistance | ≥ 5000MΩ |
Withstand voltage | 3000V |
Working current and contact resistance | |||
Contact mating diameter (mm) | Contact resistance (m2) | Working current (A), temperature rise less than 55 degrees | Applicable cable diameter (mm²) |
3 | ≤ 2 | 40A | 2.5,4,6 |
3.6 | ≤ 2 | 60A | 2.5,4,6,10 |
8 | ≤ 1 | 200A | 25,35,50 |
10 | ≤ 0.2 | 250A | 35,50,70 |
14 | ≤ 0.2 | 500A | 95,120,135,150 |
