Main technical parameters | |||
Operating temperature | -25℃~+120℃ | Relative humidity | 60%(40℃) |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times |
Shell material | PC UL94-V0 | ||
Contact member | Specification | Power contact Ø1.6mm | |
Quantity | 12 | ||
Rated current | 10A | ||
Contact resistance | 1mΩ | ||
Withstand voltage value | 1500V | ||
Surface treatment | Silver plating on nickel base | ||
Terminating form | Crimping | ||
Materials Insert pin, jack | Copper | ||
