Main technical parameters | ||||
Operating temperature | -25℃~+120℃ | Relative humidity | 60%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | |
Shell material | PC UL94-V0 | |||
Contact member | Specification | Signal contact 0.6 Policy | ||
Quantity | 96 | |||
Rated current | 2A | |||
Contact resistance | 20mΩ | |||
Withstand voltage value | 1000VDC/The center distance is 5.08mm | |||
Surface treatment | Gold plating on contact surface,tinplating on other surface | |||
Terminating form | Welding,plate joint | |||
Materials | Insert pin,jack | Copper | ||
