Main technical parameters | ||||
Operating temperature | -25℃~+120℃ | Relative humidity | 60%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | |
Shell material | PC UL94-V0 | |||
Contact member | Specification | Power contact Ø1.6mm | ||
Quantity | 8 | |||
Rated current | 10A | |||
Contact resistance | 1.6mΩ | |||
Withstand voltage value | 1500V | |||
Surface treatment | Silver plating on nickel base | |||
Terminating form | Crimping | |||
Materials | Insert pin,jack | Copper | ||
