Main technical parameters | ||||
Operating temperature | -55℃~+125℃ | Relative humidity | 98%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | |
Shell material | PET+30%GF UL94-V0 | |||
Contact member | Specification | Power contact | ||
Pin end 0.5mm material thickness hole end 0.4mm material thickness(stamping parts) | ||||
Quantity | 5 | |||
Rated current | 55A | |||
Contact resistance | 2mΩ | |||
Withstand voltage value | 3000VDC(center distance 7.62mm) | |||
Surface treatment | The contact suface is gold-plated,the rest is tinned | |||
Terminating form | Crimp,plate joint | |||
Materials | Insert pin,jack | High-conductivity copper | ||
