Main technical parameters | |||||
Operating temperature | -55℃~+125℃ | Relative humidity | 98%(40℃) | ||
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | ||
Shell material | PET+30%GF UL94-V0 | ||||
Contact member | Specification | Power contact 4#(Ø6.35) | Signal contact 20# | ||
Quantity | 2 | 7 | |||
Rated current | 120A | 5A | |||
Contact resistance | 0.6mΩ | 6.7mΩ | |||
Withstand voltage value | 1500V | 1000V | |||
Surface treatment | Silver plating on nickel base | Nickel plating | |||
Terminating form | Welding,crimping,PCB connection | ||||
Materials | Insert pin,jack | Oric halcun Beryllium copper | |||
