Main technical parameters | ||||
Operatng temperature | -55℃~+125℃ | Relative humidity | 98%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | |
Shell material | PET+30%GF UL94-V0 | |||
Contact member | Specification | Power contact Ø5.0 | Signal contact 22# | |
Quantity | 2 | 8 | ||
Rated current | 185A | 3A | ||
Contact resistance | 0.65mΩ | 10mΩ | ||
Withstand voltage value | 1500V | 1000V | ||
Surface treatment | Silver plating on nickel base | Nickel plating | ||
Terminating form | Welding,crimping,PCB connection | |||
Materials | Insert pin,jack Crown spring | Orichalcum Beryllium copper | ||
