Main technical parameters | ||||
Operating termperature | -25℃~+120℃ | Relative humidity | 60%(40℃) | |
Insulation resistance | ≥1000MΩ(normal) | Mechanical life | 500 times | |
Shell material | PC UL94-V0 | |||
Contact member | Specification | Power contact Ø2.45mm | ||
Quantity | 6 | |||
Rated current | 16A | |||
Contact resistance | ≤1mΩ | |||
Withstand voltage value | 600V | |||
Surface treatment | Silver plating on nickel base | |||
Terminating form | Crimping | |||
Materials | Insert pin,jack | Copper | ||
