Main technical parameters | ||||
Operating temperature | -25℃~+120℃ | Relative humidity | 60%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 1000 times | |
Shell material | PC UL94-V0 | |||
Contact member | Specification | Power contact Ø4mm | ||
Quantity | 3 | |||
Rated cument | 40A | |||
Contact resistance | 0.62mΩ | |||
Withstand voltage value | 1000V | |||
Surface treatment | Silver plating on nickel base | |||
Terminating fom | Crimping | |||
Materials | Insert pin,jack Lock nut | Copper Copper | ||
