Main technical parameters |
| ||||
Operatng temperature | -55℃~+125℃ | Relative humidity | 98%(40℃) | ||
≥3000MΩ | Mechanical life | 1000 times | |||
PET+30%GF UL94-V0 | |||||
specification | Power contact | ||||
quantit | 4 | ||||
Rated current | 150A | ||||
Contact resistance | 0.6mΩ | ||||
Withstand voltage value | 1500V | ||||
Surface treatment | Silver plating on nickel base | ||||
Terminating form | Welding,crimping,plate bonding | ||||
Materials | Insert pin,jack | Silver-plated copper | |||
