Main technical parameters | ||||
Operating temperature | -55℃~+125℃ | Relative humidity | 98%(40℃) | |
Insulation resistance | ≥3000MΩ(normal) | Mechanical life | 500 times | |
Shell material | PET+30%GF UL94-V0 | |||
Contact member | Specification | Power contact | Signal contact | |
Quantity | 23 | 2 | ||
Rated current | 13A | 3A | ||
Contact resistance | 3.5mΩ | 10mΩ | ||
Withstand voltage value | 1500V | 1000V | ||
Surface treatment | Silver plating on nickel base | Nickel plating | ||
Terminating form | Crimp,plate joint |
| ||
Materials | Insert pin,jack | Orichalcum |
| |
