Project | Parameter | ||
Ferrule Type | Ceramic Ferrule | ||
Shell core number | 2~32 cores | ||
Fiber Type | Single-mode G652D (G657A optional) | Multimode OM1/OM2/OM3/OM4/OM5 optional | |
Working wavelength | 1310、1550nm | 850、1300nm | |
Insertion loss (dB) | 2C≤0.3 4C≤0.5 6C≤0.7 | 2C≤0.3 4C≤0.5 6C≤0.7 | |
Return loss (dB)) | APC | / | / |
| PC | ≥50 | ≥30 |
Jumper Cable | Skin shape | Round Cable | |
| Outer sheath material | LSZH, TPU (other materials can be customized) | |
| Outer diameter (mm) | 2.0, 5.0, 7.0, 12.0 optional | |
Number of plug-in and plug-out times | >500 | ||
Tensile strength | 5.0&7.0 optical cable diameter ≥400N 12.0 optical cable diameter ≥500N | ||
Operating temperature | -40℃~+85℃ | ||
Waterproof grade | IP67 | ||
Comply with standards | GJB599A (MIL-DTL-38999) III series interface | ||
