Project | Parameter | ||
Ferrule Type | Ceramic Ferrule | MT Ferrule | |
Shell core number | 2~8 cores | 12~96 cores | |
Fiber Type | Single-mode G652D (G657A optional) | Multimode OM1/OM2/OM3/OM4/OM5 optional | |
Working wavelength | 1310、1550nm | 850、1300nm | |
Insertion loss (dB) | Ceramic 2C≤0.34C≤0.5 | MT ferrule 12C≤0.5 | |
Return loss (dB) | APC | / | / |
PC | ≥50 | ≥30 | |
Jumper Cable | Skin shape | Round Cable | |
Outer sheath material | LSZH, TPU (other materials can be customized) | ||
Outer diameter (mm) | 5.0, 7.0, 12.0 optional | ||
Number of plug-in and plug-out times | >500 | ||
Tensile strength | 5.0&7.0 optical cable diameter ≥400N 12.0 optical cable diameter ≥500N | ||
Operating temperature | 40℃~+85℃ | ||
Waterproof grade | IP67 | ||
Comply with standards | GJB599A (MIL-DTL-38999) III series interface, GJB1659A-2009 | ||
Project | Parameter |
Ferrule end face | PC |
Curvature radius (mm) | 10~25 |
Vertex offset (um) | 0~50 |
Fiber height (nm) | ±100 |
Fiber Type | Single Mode | Multimode |
Color | Black | Orange color |
