Project | Parameter | ||
Number of fiber cores | 1 core&multi-core | ||
Fiber type | Single mode G652D(G657A optional) | Multi-mode OM1/0M2/OM3/0M4/0M5 | |
Working wavelength | 1310、1550nm | 850、1300nm | |
Insertion loss(dB) | ≤0.30 | ≤0.25 | |
Return loss(dB) | APC | ≥60 | / |
PC | ≥50 | ≥30 | |
Jumpercable | Crust shape | round cable | |
Outer sheath | PCV(LSZH optional) | ||
Outer diameter | 0.9、2.0、3.0 | ||
Number of plugs and unplugs | >1000 | ||
Tensile strength | 0.9 optical cable diameter>7N 2.0&3.0 optical cable diameter>70N | ||
| -40℃~+85℃ | ||
Meet standards | IEC61753-1、IEC61755-3-1、IEC61755-3-2、YD/T 1272.4、GR-326-CORE | ||
Project | Parameter | |
Ferruleend face | PC | APC |
Radius of curvature(mm) | 10~25 | 5~12 |
Vertex offset (um) | 0~50 | 0~50 |
Fiber height(nm) | ±100 | ±100 |
Angle | / | 8±0.3° |
Fiber type | Single mode | Multimode (OM1/0M2) | 10 Gigabit Multimode (OM3) | 10 Gigabit Multimode (OM4) | 10Gigabit Multimode (OM5) |
Color | yellow | orange color | light blue | rose red | lime green |
